PNR Collins NavHub
- Assured PNT
- Military ground and maritime platforms
- NATO AQAP 2110
- ISO 9001:2015
Refresh your fleet's navigation without re-cabling every vehicle. NavHub is Collins Aerospace's modular GNSS navigation hub for military ground and maritime platforms, and AIR TEAM Intel handles the specification, integration and fleet upgrade around it.
Mission profiles
Ground vehicle fleets
Assured position, navigation and timing for vehicles that run ageing GPS navigators.
Maritime hosts
The same hub on vessels, with timing to radios and mission systems on board.
Fleet upgrade programmes
Run NavHub alongside or in place of legacy navigators, with the interface set planned once.
Sensors and systems
Modular GNSS hub
Dual receiver-card slots, so receiver technology can be refreshed without re-cabling the platform.
Platform interfaces
Ethernet, serial and CAN to the host platform's data bus, plus timing outputs to radios and mission systems.
Vehicle and vessel sensors
IMU, odometer or equivalent sensors integrated with the receiver cards.
Anti-jam pairing
On land platforms NavHub is usually paired with a Raytheon Landshield CRPA anti-jam antenna.
Key specifications
Integration scope
- Navigator
- Collins Aerospace NavHub, dual GNSS receiver-card slots
- Interfaces
- Ethernet, serial, CAN; timing outputs to radios and mission systems
- Antenna
- Raytheon Landshield CRPA on land platforms
- Work
- Specification, integration, installation support, fleet upgrades
Airborne navigation we also integrate (OEM data)
- Northrop Grumman LN-100G
- GPS/INS, 7 m CEP, −54 °C to +71 °C, MTBF 14,400 h, SAASM
- Northrop Grumman LN-251
- Embedded GPS/INS with in-flight alignment and GPS anti-jam
- Military GPS
- L3Harris M-Code receivers; Honeywell HG1930 IMU
Certification and support
Specification
Receiver cards, sensors and antenna chosen against the platform and the current navigator.
Interface planning
Data bus, timing and power planned once and reused across vehicle types.
Installation support
First-article installation and support for the fleet roll-out.
Defence quality
Work under NATO AQAP 2110 and ISO 9001:2015, Military Part-145 where aircraft equipment is involved.
AIR TEAM Engineering designs the change under EASA design approval EASA.21J.849. AIR TEAM service installs and maintains it at Kunovice (LKKU) under EASA Part-145 CZ.145.0094 and Military Part-145 CZE.145.1004, and manufactures parts under POA CZ.21G.0075. Defence quality management is certified to NATO AQAP 2110, the quality system to ISO 9001:2015. ITAR and military trade licences are in place. All approvals →
